Housing Material | Alu. Extrusion |
Finish | Powder coating |
Housing Colour | White/Grey/Black |
Diffuser | PS Diffuser |
Finish | White/Grey/Black |
Dimension (L x W x H or Dia X H) | 50 W X 70Ht |
Cut Out Dimension | NA |
Mounting | Surface Mount |
Ingress Protection | IP20 |
Input Voltage | 230V |
Wattage | 36 W(+/-10%) |
PF | 0.95 |
THD(i) | <10% & <20% |
Frequency | 50~60 Hz |
I Volt Range | 140-300V |
Driver Type | Isolated |
Surge Protection | 2.5/4.0KV |
Driver make | Argo, Philips, Osram, Fulham |
LED Make | Bridgelux, Citizen, Lumiled, Cree/Osram |
LED Lumen | 150 lm / watt |
LED Life | 50,000 hrs |
Luminous Flux | 2240 to 5600 lm |
CCT | 2700k - 6500k |
CRI | >80 >90 >95 |
Beam Angle | 120? |
Tilt Angle | Fixed |
Operating Temp. | -20?C ~ +40?C |
